Appleton GRLB150 Type LB Conduit Body 1-1/2 inch

Product Description

The APPLETON GRLB150 is a Type LB conduit body designed for use with threaded metal conduit. Constructed from malleable iron, it offers resistance to corrosion, impact, and shock. It features two 1-1/2 inch GRLB hubs for cable entry and a 72 cu-in cubic capacity. This explosionproof and dust-ignitionproof outlet box provides access for maintenance and wire pulling.

• Explosion proof, dust-ignition proof and corrosion-resistant
• Furnished with internal ground screw
• Provides great resistance to corrosion

Product Highlights

This conduit body is ideal for connecting conduit lengths, changing direction of conduit runs, and providing access for maintenance in hazardous locations.

Product Information

Standard Information

• Brand: APPLETON
• Manufacturer Part Number: GRLB150
• Country of Origin: Mexico

Technical Specifications

• Catalog Number: GRLB150
• Manufacturer: Appleton Electric
• Brand: Appleton
• Sub Brand: UNILETS
• Country of Origin: Mexico
• Made in USA: No
• Application: For Use With Threaded Metal Conduit
• Cable Entry: (2) 1-1/2 IN GRLB Hub
• Cubic Capacity: 72 CU IN
• Knockouts: No
• Material: Malleable Iron
• Special Features: Explosionproof, dust-ignitionproof; Malleable iron bodies have high tensile strength, ductility and provides great resistance to corrosion, impact and shock; Accurately tapped, tapered hub threads for tight, rigid joints and ground continuity; Furnished with copperfree (4/10 of 1 PCT maximum) aluminum cover; Function as sealing fittings when used with sealing covers; Internally threaded body with externally threaded cover; Covers have pry notches for bar or wrench; Accommodate sealing, dome, hub and union hub covers and canopies; Standard O-rings provide raintight fit NEMA 3, 4; Internal ground screw standard; Smooth rounded integral bushing in hub box protects conductor insulation; Complies with a wide range of classified area requirements; Corrosion-resistant ideal indoors or out; For pulling of wires; Connect conduit lengths and change direction of conduit runs; Provide access for maintenance
• Standard: Class 1, Zone 1 And 2 IIA And IIB, UL File Number E10444, CSA C22.2 No. 25, C22.2 No. 30, CSA 013017 Certified, Class I, Division 1 And 2, Groups B, C, D Class II, Division 1 And 2, Groups E, F, G Class III
• UPC: 781381443852
• GTIN: 00781381443852
• Item Type: Outlet Box
• Length: 8.7000 Inch
• Width: 8.7000 Inch
• Height: 7.6000 Inch
• Size: 1-1/2 in
• Cover Opening Size: 4.88 in
• Finish: Triple Coated
• Includes: Internal Ground Screw and O-Ring
• Mfg Standards/Approvals: Class 1, Zone 1 and 2 IIA and IIB, UL File No. E10444, CSA C22.2 No. 25, C22.2 No. 30, CSA 013017, Class I, Division 1 and 2, Groups B, C, D Class II, Division 1 and 2, Groups E, F, G Class III, RoHS Compliant
• Series: GR Series
• Suitable For Use With: Threaded Metallic Conduit System
• Type: LB-Style Dust-Ignitionproof Explosionproof
• Number of Outlet: 2
