Appleton GRL200 Type L Conduit Body, 2 inch, Malleable Iron, Zinc Electroplated

Product Description

The Appleton GRL200 is a two-inch conduit body made of malleable iron with zinc electroplating. This conduit body is designed for use with threaded metal conduit systems and ensures a robust connection for electrical wiring. With a cubic capacity of seventy-six cubic inches, it provides ample space for wire junctions and connections.

• Number of outlet: 2
• Material: Malleable iron
• Cover opening diameter: 4.88 inches

Product Highlights

This conduit body is suitable for both indoor and outdoor applications, providing protection against dust and moisture. The construction of this outlet box ensures high tensile strength and resistance to corrosion and impact.

Product Information

Standard Information

• Catalog Number: GRL200
• Manufacturer: Appleton Electric

Technical Specifications

• Material: Malleable iron
• Cubic Capacity: 76 CU IN
• Application: For use with threaded metal conduit
• Knockouts: No
• Height: 5.75 inches
• Width: 5.75 inches
• Depth: 4.25 inches
• Cover Opening Diameter: 4.88 inches
• Special Features: Explosionproof, dust-ignitionproof, corrosion resistant
• UPC: 781381116978
• Country of Origin: Mexico
