Appleton GRL125 Type L Conduit Body with Cover, 1-1/4 inch

Product Description

The APPLETON GRL125 is a Type L conduit body with cover, designed for use with threaded metal conduits. This 1-1/4 inch malleable iron outlet box features a zinc electroplated finish and two 1-1/4 inch GRL hubs. It provides access for maintenance and allows for changes in conduit direction.

• Explosion proof and dust-ignition proof
• Features an internal ground screw
• Offers high resistance to corrosion

Product Highlights

This conduit outlet box is ideal for general purpose wiring, wire pulling, and connecting conduit lengths in demanding environments.

Product Information

Standard Information

• Brand: APPLETON
• Manufacturer Part Number: GRL125
• Country of Origin: Mexico

Technical Specifications

• Catalog Number: GRL125
• Manufacturer: Appleton Electric
• Brand: Appleton
• Sub Brand: UNILETS
• Application: For Use With Threaded Metal Conduit
• Cable Entry: (2) 1-1/4 IN GRL Hub
• Cubic Capacity: 31 CU IN
• Knockouts: No
• Material: Malleable Iron
• Special Features: Explosionproof, dust-ignitionproof; Malleable iron bodies have high tensile strength, ductility and provides great resistance to corrosion, impact and shock; Accurately tapped, tapered hub threads for tight, rigid joints and ground continuity; Furnished with copperfree (4/10 of 1 PCT maximum) aluminum cover; Function as sealing fittings when used with sealing covers; Internally threaded body with externally threaded cover; Covers have pry notches for bar or wrench; Accommodate sealing, dome, hub and union hub covers and canopies; Standard O-rings provide raintight fit NEMA 3, 4; Internal ground screw standard; Smooth rounded integral bushing in hub box protects conductor insulation; Complies with a wide range of classified area requirements; Corrosion-resistant ideal indoors or out; For pulling of wires; Connect conduit lengths and change direction of conduit runs; Provide access for maintenance
• Standard: Class 1, Zone 1 And 2 IIA And IIB, UL File Number E10444, CSA C22.2 No. 25, C22.2 No. 30, CSA 013017 Certified, Class I, Division 1 And 2, Groups B, C, D Class II, Division 1 And 2, Groups E, F, G Class III
• Item Type: Outlet Box
• Length: 7.5000 Inch
• Width: 7.0000 Inch
• Height: 4.5000 Inch
• Size: 1-1/4 in
• Country of Origin: Mexico
• Made in USA: No
• Style: L
• Hub Size: 1-1/4 Inch
• Hub Type: External
• Number of Hubs: 2
• Hub Location: (2) Side
• Shape: L
• Cover Type: Externally Threaded
• Cover Opening Size: 3.94 in
• Enclosure: Class I Div 1 and 2 Group B C D, Class II Div 1 and 2 Group E F G, Class III, NEMA 3/4
• Approval: UL, CSA C22.2
• Number of Outlet: 2
• Product Series: GR
• Connection Type: Threaded
• Gasket Included: Yes
• Protection Rating: Indoor, Outdoor
• Approvals: CSA, UL
• Comments: Corrossion, impact & shock resistance
• Suitable For Use With: Threaded Metallic Conduit System
• Type: L-Style Dust-Ignitionproof Explosionproof
• UNSPSC: 39121308
• Finish: Triple Coated
• Capacity: 31 in³
