Appleton FSCC175 1-gang Malleable Iron Floor Box

Product Description

The APPLETON FSCC175 is a 1-gang malleable iron floor service cover and box assembly designed for flush floor electrical installations. Malleable iron construction provides the durability and impact resistance required in commercial and industrial environments where floor-mounted electrical access is needed. This type of floor box is typically installed by licensed electricians during rough-in or finish stages of construction where conduit systems terminate at floor level for power or low-voltage service access.

The FSCC175 is suited for commercial and light industrial applications where a flush, single-gang floor outlet location is required. Typical installations include office buildings, retail spaces, warehouses, and similar occupancies where floor-level electrical service points must withstand foot traffic and maintain a clean, flush appearance. The malleable iron body holds up to job-site and in-service mechanical stress better than standard cast fittings.

Key Features

• 1-gang configuration for single device or outlet mounting
• Malleable iron construction for high impact resistance and long service life
• Floor service cover box design for flush-mount conduit termination applications
• Compatible with standard conduit wiring systems used in commercial electrical installations

Compatibility

Designed as an OEM-style replacement or new-installation floor box for 1-gang flush floor electrical service applications in commercial and industrial conduit systems.

Installation Notes

Installation should be performed by a licensed electrician in accordance with the National Electrical Code (NEC) and applicable local codes. Power to the circuit must be shut off and verified de-energized before beginning work. The floor box should be set level with the finished floor surface and secured to the conduit system before concrete pour or finish flooring is applied where applicable. Do not over-tighten conduit connections into the box casting, as malleable iron threads can be damaged by excessive torque applied without proper fitting engagement.

Technical Specifications

• Gang Size: 1-Gang
• Material: Malleable Iron
• UPC: 78312620470

Standard Information

• Brand: APPLETON
• Manufacturer Part Number: FSCC175
