Appleton FF-075 Pull Elbow 3/4 Inch Female Female

Product Description

The APPLETON FF-075 is a female-to-female pull elbow fitting used in conduit systems to provide a 90-degree change of direction while allowing wire and cable to be pulled through without disassembling the raceway. The pull elbow features a removable cover that gives electricians direct access to the interior for wire pulling and maintenance. At 3/4 inch trade size, this fitting is suited for standard EMT or rigid conduit runs in commercial and industrial electrical installations. It is installed by licensed electricians working on conduit systems that require clean, accessible direction changes.

This pull elbow is used in commercial and industrial conduit installations where a 90-degree turn is needed and access to the conductor pull point must be maintained. The female-to-female configuration connects directly to threaded rigid metal conduit or intermediate metal conduit at both ends. Typical install scenarios include exposed conduit runs in mechanical rooms, industrial facilities, and other locations where NEC-compliant access fittings are required at direction changes.

Key Features

• 3/4 inch trade size fits standard threaded rigid and intermediate metal conduit
• Female-to-female threaded connections on both ends for direct conduit entry
• Removable cover provides access for wire pulling without disassembling the run
• 90-degree elbow configuration for direction changes in conduit systems
• Durable construction suitable for commercial and industrial electrical applications

Compatibility

Designed as an OEM-style fitting for 3/4 inch threaded rigid metal conduit and intermediate metal conduit systems in commercial and industrial electrical installations.

Installation Notes

Installation should be performed by a licensed electrician in accordance with the National Electrical Code (NEC). De-energize all circuits before working on the conduit system. Use appropriate pipe wrenches or conduit tools to thread the fitting onto conduit ends without over-tightening. The removable cover must remain accessible after installation per NEC requirements for pull points and junction points.

Technical Specifications

• Trade Size: 3/4 inch
• Connection Type: Female to Female (threaded)
• Configuration: 90-degree Pull Elbow
• UPC: 78312615220

Standard Information

• Brand: APPLETON
• Manufacturer Part Number: FF-075
