Appleton EXGJH-312 flexible coupling 1 x 12 replacement EXGJH312

Product Description

The APPLETON EXGJH-312 flexible coupling, with a 1 x 12 inch dimension, is designed for use in areas where vibration or movement is a problem. It can also be used in place of rigid conduit in difficult-bend situations. Suitable for wet locations, it features female end fittings with removable male nipples.

• Explosionproof and dust-ignitionproof
• Watertight construction
• Brass end fittings and bronze outer braid

Product Highlights

This flexible coupling is ideal for environments with vibration or movement, offering a solution for challenging conduit installations and wet locations.

Product Information

Standard Information

• Brand: APPLETON
• Manufacturer Part Number: EXGJH-312

Technical Specifications

• Diameter: 1 in
• Length: 12 in
• Material: Bronze, Brass
• Part Number: EXGJH312
• Brand: Appleton
• Product Series: EXGJH
• Family Series: Appleton Couplers, EXGJH Series
• Description: UNILETS Flexible Coupling, Trade Size: 1 IN, Outside Diameter: 2.06 IN, Flex Length: 12 IN, Radius: 14 IN Bending, Flexibility: Rigid And IMC, Material: Outer Bronze Braid And Inner Brass Core With Insulating Liner, End Type: 2 Male Nipples
• Conduit Type: IMC (Intermediate Metal Conduit), RMC (Rigid Metal Conduit)
• Connection Type: Threaded
• Trade Size: 1 "
• Flex Length: 12 "
• Ground Pass Through: Yes
• Protection Rating: Liquid Tight
• Composition: Bronze
• Insulated Throat: Yes
• Hazardous Location: Yes
• Approvals: CSA, UL
• End Type: (2) Male Nipple
• Fitting Material: Brass (End Fitting), Zinc Plated Steel (Nipple)
• Enclosure: Class I Group C/D, Class II Group E/F/G, Class III
• Dimensions: 2.06 in OD x 12 in L
