Appleton ESUF50 Sealing Unilet 1/2 Female

Product Description

The APPLETON ESUF50 is a sealing unilet designed to prevent the passage of gases, vapors, or flames in hazardous locations. Constructed from malleable iron with a triple-coat finish, it offers corrosion resistance. It is suitable for use with threaded rigid metal conduit (RMC) and intermediate metal conduit (IMC).

• Protects conductor insulation with a smooth, rounded integral bushing in each hub.
• Features accurately tapped, tapered hub threads for tight, rigid joints and ground continuity.
• Prevents passage of gases, vapors or flames from one portion of conduit system to another.

Product Highlights

This explosion-proof conduit sealing fitting is ideal for hazardous environments, ensuring safety and preventing explosions.

Product Information

Standard Information

• Brand: APPLETON
• Manufacturer Part Number: ESUF50
• Country of Origin: MX

Technical Specifications

• Material: Malleable Iron
• Connection: Tapered FNPT
• Brand: Appleton
• Part Number #: ESUF50
• Dimensions: 3 in L x 2.94 in W
• Finish: Tri-Coated
• Series: ESU
• Size: 1/2 in
• Suitable For Use With: IMC/Threaded Rigid Metal Conduit
• Type: Dust-Ignitionproof Explosionproof
• Country of origin: MX
• Mounting type: Surface
• Manufacturer Name: Emerson Electric
• UNSPSC: 39121311
• UPC: 00781381306355
• Part Number: ESUF50
• Manufacturer: Appleton
• Category: Conduit & Fittings
• Item Subcategory: Utility conduit fitting
• Family: ESU
• Trade Size: 1/2 inch
• Connection Type: Female Tapered Threaded
• Mounting Position: Vertical and Horizontal
• Hazardous Location Rating: Class I Div 1 & 2 Groups C, D; Class II Div 1 & 2 Groups E, F, G; Class III
• Explosionproof, Dust-Ignitionproof, Raintight: Compatible with RMC and IMC conduit
• Conduit Type: RMC / IMC
• Fitting Subtype: Universal
• Fitting Type: Sealing Fitting
• Hazard Rating: Dust-Ignitionproof / Explosionproof
• Hazard Rating Specs: Class I, Division 1, Groups A, B, C, D, Class III, Class II, Division 1, Groups E, F, G, UL 886
• MPN: ESUF50
• SKU: ESUF50
• Brand Name: Appleton
• Brand Part Number: ESUF50
