Appleton ELF90-100 1 90 Degree Female Elbow

Product Description

The Appleton ELF90-100 is a 90-degree female elbow designed for use with threaded rigid metal conduit and intermediate metal conduit (IMC). It is manufactured from malleable iron with a zinc electroplated finish for durability. The tapered FNPT connection ensures a secure fit and reliable performance.

• Trade size: 1 inch
• Material: Malleable Iron
• Standards: UL 886 and CSA C22.2 certified

Product Highlights

This elbow fitting is essential for making angled connections in conduit systems, particularly in hazardous locations.

Product Information

Standard Information

• Catalog Number: ELF90-100
• Brand: Appleton Electric

Technical Specifications

• Finish: Zinc Electroplate
• Material: Malleable Iron ASTM A47-77
• Trade Size: 1 Inch
• Connection Type: Tapered FNPT
• Bend Angle: 90 Degrees
• Application: For use with threaded rigid metal conduit and IMC
• Special Features: Explosionproof, dust-ignitionproof; smooth, rounded integral bushing protects conductor insulation
• Country of Origin: Mexico
• UPC: 78138129440
