Appleton EFD275-NL-Q 2-Gang Duplex Pilot Light Unilet

Product Description

The Appleton EFD275-NL-Q 2-Gang Duplex Pilot Light Unilet is designed for hazardous locations. This control station features explosionproof and dust-ignitionproof protection to prevent ignition of flammable atmospheres. It is suitable for chemical and petrochemical applications as well as in refineries. The enclosure is factory sealed, ensuring reliable operation without the need for additional sealing fittings.

• Explosionproof and dust-ignitionproof design
• Factory sealed to eliminate the need for sealing fittings
• Includes pilot lights for remote status indication

Product Highlights

This control station is built with durability in mind, featuring heavy-duty components that withstand harsh environments.

Product Information

Standard Information

• Brand: Appleton
• Manufacturer: Appleton Electric

Technical Specifications

• Catalog Number: EFD275-NL-Q
• Material: Malleable Iron
• Size: 3/4 IN
• Type: 2-Gang Dead-End Mounting Body
• Mounting: Lugs
• Enclosure: NEMA 7CD, 9EFG
• Standard: UL 508, 698, 1203, UL File Number E10449
• UPC: 781381272209
