Appleton EDSC175-F3W Explosion-Proof Tumbler Switch 120 to 277 VAC 20 A

Product Description

Appleton EDSC175-F3W is an explosion-proof and dust-ignitionproof tumbler switch designed for use in hazardous locations. This product is suitable for environments where ignitable vapors, gases, or highly combustible dusts are present, making it ideal for chemical and petrochemical industries, refineries, and other process areas.

• Explosionproof, Dust-Ignitionproof
• UL Listed for Class I, Groups B, C, D and Class II, Groups E, F, G
• Voltage rating of 120 to 277 VAC with a current rating of 20 Amps

Product Highlights

This switch features a factory-sealed design that confines arcing, preventing ignition during lighting connect and disconnect operations. Its robust construction meets demanding environmental conditions.

Product Information

Standard Information

• Brand: Appleton
• Manufacturer: Appleton Electric

Technical Specifications

• Catalog Number: EDSC175-F3W
• Type: EDSC Series 1-Gang 3-Way Tumbler Switch
• Finish: Zinc Electroplate, Epoxy Powder Coat
• Voltage: 120 - 277 VAC
• Amperage: 20 Amp
• Material: Copper-free Aluminum, Malleable Iron, Nylon
• Enclosure Rating: NEMA 7CD, 9EFG
• Application: For use in classified areas with ignitable vapors, gases, or dusts
