Appleton CHM-200 2 in COND HUB RMC/IMC

Product Description

The APPLETON CHM-200 is a 2 IN COND HUB RMC/IMC. These raintight conduit hubs can be used with RMC and IMC. Type CHM are general purpose fittings. Type CHM 11T are insulated throat form fittings with a bonding locknut. Suitable for use with service entrance conduit.

• Female bushed nipple type
• Female thread for rigid conduit and IMC
• Takes less space

Product Highlights

The APPLETON CHM-200 2 IN COND HUB RMC/IMC is a fitting suitable for use with service entrance conduit.

Product Information

Standard Information

• Brand: APPLETON
• Manufacturer Part Number: CHM-200

Technical Specifications

• Manufacturer Part Number: CHM200
• Manufacturer: Appleton
• Product Series: CHM
• Family Series: Appleton Fittings, CHM Series
• Description: 2 IN COND HUB RMC/IMC
• Conduit/Cable Type: IMC (Intermediate Metallic Conduit), RMC (Rigid Metallic Conduit)
• Connection Type: Screw-In
• Angle: Straight
• Trade Size: 2 "
• Hub Type: Male NPT Thread
• Grounding: No
• Insulated Throat: No
• Jacketed: No
• Material: Malleable Iron
• Composition: Metallic
• Protection Rating: Rain Tight
• NEMA Rating: NEMA FB1
• Hazardous Location: No
• Approvals: CSA, UL
• Component: Conduit Hub
