Appleton CG-87100S 1 Steel Liquidtight Cort and Cable Connector

Product Description

The Appleton CG-87100S is a liquidtight strain relief connector made from machined steel. This 1 inch connector fits cable diameters from seven eighths to one inch. It features a threaded hub connection and meets NEMA 3R rating standards, making it suitable for wet and dry locations. This connector is essential for sealing electrical connections against dust, dirt, oil, and moisture.

• Material: Machined Steel
• Conductor Range: 7/8 to 1 inch
• NEMA Rating: 3R

Product Highlights

Designed for flexible type neoprene, hypalon, and PVC jacketed power or control cables, this connector provides a secure and reliable connection.

Product Information

Standard Information

• Manufacturer: Appleton Electric
• UPC: 78138144948

Technical Specifications

• Catalog Number: CG-87100S
• Trade Size: 1 inch
• Connection: Threaded Hub
• NEMA Rating: 3R
• Applications: Sealing electrical connections in wet or dry locations
• Dimensions: 1-3/4 inches height
• Standard Compliance: Class I, Division 2; Class II, Division 1 and 2; Class III; UL 514B
• Country of Origin: Mexico
