Appleton CES-6034 60 Amp 3-Wire 4-Pole CES Receptacle

Product Description

The Appleton CES-6034 is a 60 amp, 3-wire, 4-pole receptacle designed for use in hazardous locations. This product provides explosionproof protection for stationary or portable equipment. Manufactured by Appleton Electric, this receptacle features a Slide-Lok design that enforces a three-stage power insertion process to reduce the risk of unintended activation or accidental disconnection.

• Constructed of factory-sealed malleable iron and copperfree aluminum cover.
• Features deeply recessed contacts to minimize accidental touch risks.
• Meets rigorous safety standards including UL and CSA certification.

Product Highlights

Ideal for industrial environments where safety and reliability are critical. Used in applications such as lighting systems, conveyors, and compressors.

Product Information

Standard Information

• Brand: Appleton
• MPN: CES-6034

Technical Specifications

• Voltage: 125 - 250 Volt
• Amperage: 60 Amp
• Number of Poles: 4
• Number of Wires: 3
• Material: Copperfree aluminum and malleable iron
• Mounting Type: Surface mount
• Hub Size: 1-1/4 inches
• Horsepower: 5 HP at 125 - 250 Volt
