Appleton AP20023E 200 Amp Plug Assem 3p S2 2.500

Product Description

The APPLETON AP20023E is a pin and sleeve plug designed for various heavy-duty applications. It is suitable for compressors, motor generator units, pumps, and welding equipment. The plug features a weatherproof construction and is rated for 600 VAC/250 VDC at 50 to 400 Hz with a current rating of 200 Ampere.

• Weatherproof construction
• Rated for 600 VAC/250 VDC at 50 to 400 Hz
• Epoxy powder coated copper-free aluminum construction

Product Highlights

This Appleton pin and sleeve plug provides a safe and reliable power connection for heavy-duty equipment in demanding environments.

Product Information

Standard Information

• Brand: APPLETON
• Manufacturer Part Number: AP20023E
• Country of Origin: Mexico

Technical Specifications

• Catalog Number: AP20023E
• Manufacturer: Appleton Electric
• Brand: Appleton
• Country of Origin: Mexico
• Made in USA: No
• UPC: 781381131186
• GTIN: 00781381131186
• Type: Compressor, Motor Generator Unit, Polarized, Pump, Welding, Spring Door
• Constructional Feature: Weatherproof
• Voltage Rating: 600 VAC 1-Phase at 50 to 400 Hz, 250 VDC
• Current Rating: 200 Ampere
• Number of Poles: 3
• Number of Wires: 2
• Grounding Style: 2, Shell, Extra Pole
• Minimum Cable Outer Diameter: 1.875 Inch
• Maximum Cable Outer Diameter: 2.5 Inch
• Material: Epoxy Powder Coated Copper Free Aluminum
• Approval: UL 1682/1689/50E, CSA C22.2
• Contact Material: Brass
• Application: Compressor, Generator Unit, Pump, Shipping Docks, Shipping Ports, Welding
• Family Series: Appleton Plugs & Receptacles
• Connection Type: Plug
• Connection Description: Straight
• Voltage: 250 V, 600 V
• Frequency: 50-400 Hz
• Lockout-Tagout: No
• Auxiliary Contact: None
• Built-In Strain Relief: No
• Wire Size Range: 2/0 AWG
• Terminal Type: Pressure Wire
• Approvals: CSA, UL
• Comments: Shell and Extra Pole, For Ordinary Locations
• Component: Plug Assembly
• Amperage Rating: 200 A
• NEMA Rating: NEMA 3/3R/4/4X
• Series: AP Series
• Temperature Rating: -40 to 225 deg F
• Wire Size: 2/0 AWG
• Amps Rating: 200A
• Case Material: Metallic
• Min. Cable Outer Dia.: 1.875"
