Appleton AEP3461 Style-2 grounding 4-pole clamping ring plug 30 A (5/8-3/4 in)

Product Description

Appleton AEP3461 is a Style-2 grounding clamping ring plug from the AE series, rated 30 A and suitable for 600 VAC and 250 VDC service. The 4-pole, 3-wire plug accepts 14–8 AWG conductors and 5/8–3/4 inch cable diameters, and features a copper-free aluminum epoxy powder coat housing with a weatherproof clamping ring and neoprene gasket for raintight assembly.

• 4-pole, 3-wire design with grounding style 2 (shell and extra pole); accepts 14–8 AWG wire.
• Rated 30 A at 600 VAC and 250 VDC; plug cable diameter 5/8–3/4 in with built-in strain relief.
• Copper-free aluminum housing with epoxy powder coat, pressure wire terminal, solid brass contacts and beryllium copper springs; floating self-aligning contacts and fiberglass-reinforced phenolic insulating blocks.

Product Highlights

AE series clamping ring plug, 30 A, 600 VAC/250 VDC, 4P/3W, 14–8 AWG, weatherproof with pressure wire terminal

Product Information

Standard Information

• Brand: APPLETON
• Manufacturer Part Number: AEP3461
• Country of Origin: Mexico
