Appleton 870F 2-1/2-3 Cast Cnd Bdy Cvr

Product Description

The Appleton 870F is designed as a blank clip cover for outlet bodies with a hub size of two and a half to three inches. This product features a screw-in mounting system and is made from cast Grayloy iron. It is suitable for use with FM7 Unilet conduit outlet bodies. The cover provides protection and a clean finish for electrical installations.

• Hub size: Two and a half to three inches
• Material: Cast Grayloy iron
• Standard compliance: UL 514A, UL 514B

Product Highlights

The Appleton 870F offers a durable design with a unique Wedge-Lok feature that allows for easy removal without damage to the conduit. This makes installation and maintenance straightforward for professionals in the field.

Product Information

Standard Information

• Brand: Appleton
• Manufacturer: Appleton

Technical Specifications

• Form: 7
• Type: Blank Clip Cover With Screw
• Color: Gray
• Finish: Triple-Coat (Zinc Electroplate; Chromate And Epoxy Powder Coat)
• Weight: 2.52 lbs
• Mounting: Screw-In
• Hub Size: 2-1/2 - 3 inches
• Material: Cast Grayloy-Iron
• Standard: UL 514A; UL 514B; UL File Number E2527; CSA C22.2 No. 18.3
