Appleton 8466 4-inch Square Mud Ring 1-gang

Product Description

The APPLETON 8466 is a 4-inch square switch ring, also known as a mud ring or raised plaster ring, designed for use with standard 4-inch square electrical boxes. This 1-gang ring raises the device mounting surface 1-1/4 inches above the box face, allowing flush device installation in walls with varying drywall or plaster thicknesses. It is a standard component in commercial and residential electrical rough-in work, installed by licensed electricians during the finishing stage of a wiring project. The ring accepts standard single-gang wiring devices and cover plates.

This switch ring is used in commercial construction, tenant improvement work, and residential installations where 4-inch square outlet or device boxes are the specified box type. It is commonly installed in drywall, plaster, and masonry applications. The 1-1/4-inch raised depth accommodates typical wall finishing materials and brings the device mounting surface to the finished wall plane.

Key Features

• 1-gang configuration accepts standard single-gang wiring devices and wallplates
• 1-1/4-inch raised depth for compatibility with common drywall and plaster thicknesses
• Designed for use with 4-inch square electrical boxes
• Low-profile ring at 0.290 inches overall thickness for a clean finished appearance
• Standard electrical accessory for commercial and residential rough-in applications

Compatibility

Designed as an OEM-style replacement and standard accessory for use with 4-inch square electrical device boxes in residential and commercial wiring installations.

Installation Notes

Installation is performed by a licensed electrician. Power must be shut off at the circuit breaker before installing or adjusting any box accessories or wiring devices. The ring is secured to the face of the 4-inch square box using the box mounting screws. Follow applicable NEC requirements for box fill, device support, and cover plate installation.

Technical Specifications

• Box Size: 4 inches square
• Gang Configuration: 1-Gang
• Raised Depth: 1-1/4 inches
• Dimensions (L x W x H): 8.9 inches x 8.9 inches x 0.290 inches
• Weight: 40 pounds
• UPC: 68785577650

Standard Information

• Brand: APPLETON
• Manufacturer Part Number: 8466
