Appleton 480F 1-1/4 IRON CND BDY CVR

Product Description

The Appleton 480F is a blank cover designed for use with FM8 conduit outlet bodies. This cover is made from cast grayloy-iron to ensure durability. It features a screw-in mounting design, making installation straightforward. The cover has a hub size of one and one quarter inches, suitable for a variety of electric applications.

• Made from cast grayloy-iron
• Mounting type is screw-in for easy installation
• Designed for FM8 conduit outlet bodies

Product Highlights

This product includes stainless steel screws for reliable fastening. It also offers a wiring capacity of one point five cubic inches, complying with NEC standards.

Product Information

Standard Information

• Material: Cast grayloy-iron
• Manufacturer: Appleton

Technical Specifications

• Hub Size: One and one quarter inches
• Finish: Triple-coat (zinc electroplate, chromate and epoxy powder coat)
• Color: Gray
• Enclosure: NEMA 3R
• Form: Eight
• Standard Compliance: UL 514A, UL File Number E2527, CSA C22.2 No. 18.3
• Application: For FM8 conduit outlet bodies
• Special Features: Stainless steel screws; wiring capacity of one point five cubic inches
