Apollo Valves SS-6-DTTM-4 Butterfly Valve, 6 inch, Stainless Steel

Product Description

The Apollo Valves SS-6-DTTM-4 is a Class 300 butterfly valve. It features a stainless steel disc and a fourteen-four PH stainless steel stem. The valve has 316 stainless steel metal seats and a lever operator, making it suitable for standard service applications. This valve is designed with a wafer type connection. Use it for liquids with a maximum operating pressure of seven hundred twenty psi.

• Stainless steel housing material (ASTM A351 CF8M)
• Multi-bolt retainer for seat support
• Suitable for bi-directional dead-end service

Product Highlights

This valve is designed for durability and reliability in various fluid control applications.

Product Information

Standard Information

• Manufacturer: Aalberts integrated piping systems Americas, Inc. (Apollo)
• Series: 230L 230W Series Butterfly Valves

Technical Specifications

• Nominal Diameter: DN 150
• Size: 6 in
• Connection Type: Wafer type
• Maximum Operating Pressure Liquid: 720 psi
• Materials: stainless steel (ASTM A351 CF8M)
• Operation: Lever handle
• Finishing: None
