Apollo Valves MA212 Press Adapter Male Pxmpt 2.5 in

Product Description

The APOLLO VALVES MA212 is a large-diameter male PxMPT press adapter designed for copper press fitting systems. It connects press-style copper tubing to male pipe threads, eliminating the need for soldering or open flame at the joint. The body is constructed from low-lead dezincification-resistant brass, meeting lead-free requirements for potable water applications. Internal components include a stainless-steel solid cross-section grab ring, a nylon separation ring, and an EPDM o-ring. The adapter is manufactured to ASTM material and dimensional standards. Licensed plumbers and pipefitters install this fitting using a compatible press tool with the appropriate jaw set for 2.5-inch connections.

This adapter is suited for residential and commercial plumbing systems where press-fit copper piping meets threaded pipe connections. The 2.5-inch size places it in large-diameter applications such as main supply lines, commercial water distribution, and mechanical room piping. The male NPT end threads directly into flanges, valves, or equipment with a corresponding female threaded port. The fitting is rated for potable water service and complies with low-lead content standards applicable in states and jurisdictions that enforce reduced lead requirements in plumbing components.

Key Features

• Low-lead dezincification-resistant brass body meets potable water lead-free requirements
• Patented stainless-steel solid cross-section grab ring provides a secure mechanical connection
• EPDM o-ring delivers a reliable, long-term watertight seal
• Nylon separation ring maintains component alignment during assembly
• Leak Before Press technology provides a visual indicator if a joint has not been fully pressed
• Break Away Band (Patent 9,532,451) serves as a visual confirmation element prior to pressing
• No soldering or open flame required at the connection point

Compatibility

Designed for use in ApolloPress large-diameter copper press fitting systems; the 804 series PxMPT configuration is intended for 2.5-inch copper press tubing transitioning to a male NPT threaded connection. Verify press tool jaw compatibility with 2.5-inch press fittings before installation.

Installation Notes

Installation must be performed by a licensed plumber or pipefitter in accordance with applicable local plumbing codes and ASTM standards. Shut off and depressurize the water supply and drain the line before making any connections. Use a manufacturer-approved press tool with the correct jaw profile for 2.5-inch fittings; do not attempt to press fittings with incompatible tooling. Inspect the o-ring and grab ring for damage before pressing, and confirm the Break Away Band is intact as a pre-press visual check.

Technical Specifications

• Connection Type: Press x Male NPT (PxMPT)
• Size: 2.5 inches
• Body Material: Low-lead dezincification-resistant brass
• Grab Ring Material: Stainless steel (solid cross-section)
• Separation Ring Material: Nylon
• Seal Material: EPDM o-ring
• Lead Compliance: Low lead (international low lead / LD 804)
• Material Standard: ASTM
• Patent: 9,532,451 (Break Away Band)

Standard Information

• Brand: APOLLO VALVES
• Manufacturer Part Number: MA212
