Apollo Valves CAP114 Press Tube Cap 1-1/4 in Copper

Product Description

The APOLLO VALVES CAP114 is a small-diameter press-style tube cap designed for use in copper press-fit piping systems. Built around a lead-free, dezincification-resistant copper body and sealed with an EPDM o-ring, this cap terminates 1-1/4 inch press tube ends without soldering or open flame. It is manufactured to ASTM material and dimensional standards, making it a code-consistent choice for service and installation work. Licensed plumbers and pipefitters working on press-fit systems use this cap for dead-end terminations, system commissioning, and temporary or permanent line closures.

The CAP114 is suited for residential and light commercial plumbing and hydronic applications where press-fit copper connections are already in use. Its small-diameter profile fits the ApolloPress 817 series product line. The leak-before-press design provides a built-in visual check: if the cap is not fully pressed, the system will weep at that joint under pressure, alerting the installer before full system pressurization.

Key Features

• Lead-free dezincification-resistant copper body meets ASTM material standards
• EPDM o-ring provides a reliable, chemical-compatible seal for press connections
• Leak-before-press technology flags incomplete presses during pressure testing
• No-flame installation eliminates soldering and associated fire risk
• 1-1/4 inch press-fit end connection for standard copper tube
• ApolloPress 817 small-diameter series construction

Compatibility

Designed as an OEM-style press-fit cap for 1-1/4 inch copper tube within the ApolloPress 817 small-diameter press system product line.

Installation Notes

Installation requires a compatible press tool and jaw set rated for the connection size and fitting series. Shut off and depressurize the system before fitting the cap onto the tube end. Confirm the o-ring is fully seated before pressing. Inspect the pressed joint visually and verify with a low-pressure leak test before returning the system to service.

Technical Specifications

• Connection Size: 1-1/4 inches
• Connection Type: Press-fit
• Body Material: Lead-free dezincification-resistant copper
• Seal Material: EPDM o-ring
• Series: ApolloPress 817 Small Diameter
• Construction Standard: ASTM materials and standards
• Lead Free: Yes

Standard Information

• Brand: APOLLO VALVES
• Manufacturer Part Number: CAP114
