Apollo Valves 94alf10101a Ball Valve 1/4 in Full Port Brass

Product Description

The APOLLO VALVES 94alf10101a is a 1/4-inch lead-free forged brass two-piece full-port ball valve rated at 600 CWP. It uses a threaded end connection and is designed for use in water distribution and plumbing systems where lead-free compliance is required. The full-port design minimizes flow restriction, and the forged brass body provides durability in demanding service conditions. This valve meets NSF/ANSI 61 and NSF/ANSI 372 standards for drinking water system components. It is installed by licensed plumbers and pipefitters in both residential and light commercial applications.

This valve is suited for potable water service lines, distribution manifolds, and isolation applications where a compact 1/4-inch shutoff is needed. Its threaded connection makes it compatible with standard NPT pipe fittings. The lead-free forged brass construction meets regulatory requirements for use on public water supplies and building plumbing systems subject to state and local lead-free mandates. Certifications from CSA, UL, and FM make it appropriate for jurisdictions with strict listing requirements.

Key Features

• Lead-free forged brass body meets NSF/ANSI 61 and NSF/ANSI 372 for potable water service
• Full-port design allows unrestricted flow through the 1/4-inch line
• 600 CWP rating provides a high-pressure safety margin for standard plumbing service
• Two-piece construction allows internal access for service and inspection
• Threaded end connections for straightforward installation with standard NPT fittings
• CSA, UL, and FM certified for use in jurisdictions requiring listed components

Compatibility

Designed as an OEM-style replacement or new-installation ball valve for 1/4-inch threaded pipe systems in residential and commercial plumbing applications requiring lead-free, NSF-compliant shutoff valves.

Installation Notes

Installation should be performed by a licensed plumber in accordance with the International Plumbing Code and applicable local codes. Shut off the water supply and depressurize the line before beginning work. Apply thread sealant or PTFE tape to male threads per standard practice. Do not over-tighten threaded connections, as this can damage the valve body or adjacent fittings.

Technical Specifications

• Size: 1/4 inch
• Cold Working Pressure (CWP): 600 psi
• Body Material: Forged Brass
• Port Type: Full Port
• Pieces: 2
• Connection Type: Threaded
• Lead Free: Yes
• Certifications: CSA, UL, FM, NSF/ANSI 61, NSF/ANSI 372

Standard Information

• Brand: APOLLO VALVES
• Manufacturer Part Number: 94alf10101a
