Apollo Valves 94ALF20901A 2-1/2 x 2-1/2 C x C 400 PSI CWP Lead-Free

Product Description

The Apollo Valves 94ALF20901A is a two-piece, straight ball valve designed for plumbing applications. It features a nominal size of two and a half inches by two and a half inches with female soldered end connections. The valve is built to withstand a pressure rating of four hundred PSI CWP and a temperature rating ranging from zero to four hundred degrees Fahrenheit. This lead-free valve has a body made from dezincification resistant brass and a ball made of 316 stainless steel, ensuring durability and longevity.

• Designed for plumbing, HVAC, and portable water applications.
• Lead-free construction meets NSF/ANSI standards.
• Equipped with a blowout-proof stem and adjustable stem packing nut.

Product Highlights

This valve's full port design allows for maximum flow capacity and reduces potential pressure loss. The handle is made of plated steel and features a distinct grip for easy operation.

Product Information

Standard Information

• Manufacturer: Conbraco
• UPC: 670750968440

Technical Specifications

• Ball Material: 316 Stainless Steel
• Body Material: Dezincification Resistant Brass
• End Connection: Female Soldered x Female Soldered
• End to End Distance: 6.28 inches
• Handle Material: Plated Steel
• Port Type: Full
• Pressure Rating: 400 PSI CWP
• Temperature Rating: 0 to 400 degrees Fahrenheit
• Inclusions/Features: Blowout-proof stem, adjustable stem packing nut, distinct white handle grip
