Apollo Valves 89-505-01A Ball Valve 1 Inch Npt

Product Description

The APOLLO VALVES 89-505-01A is a spring-return ball valve designed for use in fluid control systems requiring automatic valve closure upon loss of actuating force. Built with a carbon steel body and a 1-inch NPT threaded connection, this valve returns to its default position when actuation pressure or signal is removed. It is sold as a single unit and is a functional component in piping systems where fail-safe positioning is required. Licensed plumbers, pipefitters, and mechanical contractors are the typical installers for this type of valve in both commercial and industrial applications.

This ball valve is suited for use in plumbing, HVAC hydronic systems, and light industrial piping where a 1-inch NPT threaded connection is required. The spring-return mechanism makes it appropriate for automated or semi-automated systems where the valve must default to a set position during power loss or system shutdown. It is commonly installed in equipment rooms, mechanical spaces, and process piping where reliable shutoff and fail-safe behavior are priorities.

Key Features

• Spring-return mechanism provides automatic fail-safe positioning
• 1-inch NPT threaded connection for standard pipe compatibility
• Carbon steel body construction for durability in demanding service conditions
• Sold individually as a single unit
• Weighs 2.35 pounds for easy handling during installation

Compatibility

Designed as an OEM-style replacement or direct installation component for piping systems requiring a 1-inch NPT spring-return ball valve in carbon steel construction.

Installation Notes

Installation should be performed by a licensed plumber or pipefitter in accordance with applicable local mechanical and plumbing codes. Shut off and depressurize the system fully before removing or installing any valve. Use appropriate pipe thread sealant or PTFE tape on NPT threads and verify the spring-return direction matches system fail-safe requirements before completing installation.

Technical Specifications

• Connection Type: 1-inch NPT
• Body Material: Carbon Steel
• Actuation Type: Spring Return
• Weight: 2.35 pounds
• Sold As: Each
• UPC: 670750153730

Standard Information

• Brand: APOLLO VALVES
• Manufacturer Part Number: 89-505-01A
