Apollo Valves 83B24704 Full Port Class 600 3 Piece Carbon Steel Ball Valve with 2-1/4 inches Stem Extension 1-1/2 inches (2 x Socket Weld)

Product Description

The APOLLO VALVES 83B24704 Full Port Class 600 3 Piece Carbon Steel Ball Valve features a robust three-piece configuration with enclosed fasteners. Its swing-out center section and full port facilitate maximum fluid flow. The valve is furnished with stainless-steel trim and hardware, enhancing its resistance to wear and corrosion.

• 3-piece construction w/ enclosed fasteners
• Full port
• Stainless steel trim & hardware

Product Highlights

This ball valve includes a swing-out center section, pressure balanced solid ball, and adjustable multi-piece PTFE packing. It is fire safe to API607 and suitable for vacuum service.

Product Information

Standard Information

• Brand: APOLLO VALVES
• Manufacturer Part Number: 83B24704
• Country of Origin: United States

Technical Specifications

• DN1: 1-1/2"
• DN2: 1-1/2"
• etim-class: EC011343 Ball valve
• Housing material: Steel
• Surface protection housing: None
• Material ball: Stainless steel
• Material spindle: Stainless steel
• Nominal diameter connection 1: DN 40
• Connection 1: Soldered sleeve
• Nominal diameter connection 2: DN 40
• Connection 2: Soldered sleeve
• Housing construction: 3-part
• Full bore: Yes
