Apollo Valves 83B-005-01 Ball Valve Seal Repair Kit

Product Description

The APOLLO VALVES 83B-005-01 is a seal repair kit designed for the 83B Series three-piece, full port, Class 600 carbon steel ball valves. The kit supplies the RPTFE (reinforced polytetrafluoroethylene) seals and soft goods needed to restore valve performance without replacing the entire valve body. This type of service kit is used by licensed plumbers, pipefitters, and industrial maintenance technicians performing scheduled maintenance or emergency repairs on high-pressure ball valve assemblies in commercial and industrial piping systems.

This repair kit applies to full port, three-piece carbon steel ball valves rated at Class 600 pressure service. Three-piece valve construction allows the body to be disassembled in-line, making seal replacement practical without removing the valve from the piping system. Typical installations include high-pressure industrial process lines, steam and condensate systems, and commercial mechanical rooms where carbon steel valves are the standard specification.

Key Features

• RPTFE seat and seal material rated for Class 600 service pressure
• Designed for full port, three-piece carbon steel ball valve configuration
• Restores valve sealing performance without full valve replacement
• Sold as a single service kit containing all required soft goods for one valve

Compatibility

Designed as an OEM-style seal replacement kit for APOLLO VALVES 83B Series full port Class 600 three-piece carbon steel ball valves.

Installation Notes

Seal replacement on high-pressure ball valves should be performed by a licensed plumber or pipefitter. Isolate and depressurize the line completely before disassembling the valve, and verify zero pressure at the work point before opening the valve body. Three-piece body disassembly and reassembly should follow torque and sequence procedures outlined in the valve manufacturer service documentation. Work on steam or high-pressure systems may be subject to local mechanical codes and inspection requirements.

Technical Specifications

• Series: 83B
• Valve Type: Full Port Three-Piece Ball Valve
• Body Material: Carbon Steel
• Seal Material: RPTFE
• Pressure Class: Class 600
• Kit Size: 1 inch
• Unit of Measure: Each
• UPC: 670750124754

Standard Information

• Brand: APOLLO VALVES
• Manufacturer Part Number: 83B-005-01
