Conbraco 77F10701 1-1/2 NPT x NPT Ball Valve 600 PSI CWP 150 PSI SWP

Product Description

The Conbraco 77F10701 is a 1-1/2 NPT x NPT ball valve designed for various applications. It features a chrome plated brass ball and a forged brass alloy body. This valve provides reliable operation in commercial settings.

• Rated for 600 PSI CWP and 150 PSI SWP
• Full port design for optimal flow
• Compatible with multiple applications including HVAC and irrigation

Product Highlights

Durable two-piece construction with a lever handle for easy operation.

Product Information

Standard Information

• Manufacturer: Conbraco
• Model: 77F

Technical Specifications

• Nominal Size: 1-1/2 Inch
• End Connection: Threaded x Threaded
• End to End Distance: 4 Inch
• Body Material: ASTM B283 C37700 Forged Brass Alloy
• Ball Material: ASTM B16/B283 C36000/C37700 Chrome Plated Brass
• Stem Material: ASTM B16 C36000 Brass
• Seat Material: RPTFE
• Seal Material: RPTFE
• Handle Material: Plated Steel/Insulated Polyvinyl
• Port Type: Full
• Temperature Rating: 400 Deg F
• Pressure Rating: 600 PSI CWP, 150 PSI SWP
• Features: Blowoutproof Stem, Adjustable Stem Packing, Silicone-Free Assembly
• Applications: Commercial, Fuel Gas, Fire Protection, Irrigation, HVAC, Plumbing
• Applicable Standards: UL, CSA, CUPC, FM 1140
