Apollo Valves 77F-105-01 Full Port Ball Valve 2-Piece 1 Inch NPT 150 PSI SWP 600 PSI CWP

Product Description

The Apollo Valves model 77F-105-01 ball valve ensures reliable shut-off in plumbing, HVAC, and fuel gas applications. Featuring a forged brass body and a full-port design, this valve allows maximum flow and minimal pressure drop.

• Optimized for use in various temperatures, supporting a range from 0 to 400 degrees Fahrenheit.
• Robust 150 PSI SWP and 600 PSI CWP ratings handle demanding applications.
• Lead-free construction meets all applicable health and safety standards.

Product Highlights

Additional features include corrosion-resistant materials, adjustable stem packing, and a blowout-proof stem that ensure the valve's durability and longevity.

Product Information

Standard Information

• End Connections:: Female Threaded x Female Threaded
• Body Material:: C37700 Forged Brass

Technical Specifications

• Port Type:: Full
• Pressure Ratings:: 150 PSI SWP, 600 PSI CWP
• Temperature Capability:: 0 to 400 Deg F
• Valve Size:: 1 inch
• Standards Met:: UL, CSA, IAPMO IGC-157, FM 1140, ISO 9001, MSS-SP-110
