Apollo Valves 77CLF24501A 1 in. Bronze Full Port Solder 600# Ball Valve

Product Description

The Apollo Valves 77CLF24501A is a bronze full port solder ball valve designed for reliable service in commercial applications. This valve features a lead-free DZR bronze construction, ensuring durability and compliance with safety standards. The blow-out proof stem design enhances performance and user safety.

• Lead-free bronze construction
• Blow-out proof stem design
• Temperature rated up to four hundred fifty degrees Fahrenheit

Product Highlights

This ball valve is suitable for use with saturated steam up to one hundred fifty psi and can handle pressures up to six hundred psi CWP. It features RPTFE seats and seals for improved performance and longevity.

Product Information

Standard Information

• Type: 2-Piece, Full-Port
• Model: 77CLF-240A

Technical Specifications

• Ball Material: 316 Stainless Steel
• Connection Size: 1 in
• Connection Type: Solder
• Pressure Rating: 600 psi CWP, 150 psi WSP
• Body Material: Lead-Free Bronze
• Seal Material: RPTFE
• Temperature Rating: 450 deg F
• Standards/Certifications: MSS SP-11, ANSI/CAN/NSF 61 and 372
