Apollo Valves 670750692451 2-Piece Ball Valve 3 in (Replacement 76-100-27)

Product Description

Apollo Valves 670750692451 is a 2-piece standard configuration ball valve from the 76-100 series with a stainless steel body and FNPT connections. The valve is a 3 in nominal unit with standard port, 2-1/2 in orifice, 6-3/4 in inlet-to-outlet length and a 370 Cv flow coefficient. Softgoods are RPTFE seats, PTFE seals and MPTFE packing; ball and stem are 316 stainless steel with a lever actuator and mounting pad.

• 3 in nominal, FNPT end style, standard port with 2-1/2 in orifice and 370 Cv flow coefficient
• 316 stainless steel ball and stem; body per ASTM A276 and ASTM A351-CF8M; seats RPTFE, seals PTFE, packing MPTFE
• Lever actuator, mounting pad, adjustable packing gland, blowout-proof stem design; rated for 150 psig (working) and 2000 psig (test/seat) for gas and water — verify intended rating with manufacturer

Product Highlights

3 in FNPT 2-piece ball valve, 316 stainless steel construction, 370 Cv, replacement MPN 76-100-27

Product Information

Standard Information

• Brand: APOLLO VALVES
• Manufacturer Part Number: 670750692451
• Country of Origin: Domestic

Technical Specifications

• Brand: Apollo Valves
• Manufacturer Part Number: 670750692451
• Model Number: 76-100-01
• Replacement MPN: 76-100-27
• Series: 76-100 Series
• Type: 2-Piece
• Nominal Size: 3 in
• Connection Type: FNPT
• End Style: FNPT
• Port Type: Standard
• Orifice Size: 2-1/2 in
• Flow Coefficient (Cv): 370 Cv
• Body Material: Stainless Steel (ASTM A276, ASTM A351-CF8M)
• Ball Material: 316 Stainless Steel
• Stem Material: 316 Stainless Steel
• Seat Material: RPTFE
• Seal Material: PTFE
• Packing Material: MPTFE
• Actuator Type: Lever
• Handle Material: Stainless Steel
• Inlet to Outlet Length: 6-3/4 in
• Top to Inlet Center: 3.38 in
• Pressure Rating: 150 psig (working); 2000 psig (possible test/seat rating) – verify with manufacturer
• Pressure Class: 250 lb
• Softgoods Material: MPTFE/PTFE
• Includes: Mounting pad; Adjustable packing gland
• Weight: 16.79 lbs
• Country of Origin: US
• Standards and Approvals: ASTM A351 CF8M Body; ASTM A276 316 Ball/Stem; MSS SP-110; MR0103 (2012); NSF/ANSI 61-8; NSF 372; NACE MR0175 (2000); PROP65
