Apollo Valves 61Y75601 bronze y-pattern swing check valve 1-1/4 inches

Product Description

The APOLLO VALVES 61Y75601 Model 168T (61Y-75x Series) Swing Check provides a cost-effective alternative to globally sourced check valves. These valves are cast, machined, assembled, and tested in South Carolina. Apollo swing checks are ideal for steam and liquid service and can be installed in most plumbing and heating systems. Apollo swing checks can be installed in either horizontal or vertical lines with upward flow.

• Renewable Bronze Seat Disc
• NPT Connection
• Optimum Flow Capacity

Product Highlights

The APOLLO VALVES 61Y75601 is made in the USA. It features dezincification resistant bronze construction and is factory tested to MSS SP-80.

Product Information

Standard Information

• Brand: APOLLO VALVES
• Manufacturer Part Number: 61Y75601
• Country of Origin: US

Technical Specifications

• size: 1-1/4"
• materials: bronze
• connection type: FPT - female thread conical (NPT), FPT - female thread conical (NPT)
• country of origin: United States
• brand: Apollo
• series: 61Y Series Check Valves
• product type: 61Y75X01
• Suitable for medium: Liquid
• Housing material: Bronze
• Surface protection: Untreated
• Connection: Internal thread conical (NPT)
• Body Material: Bronze
• End Style: NPT
• Flow Rate: 39 gpm
• Low Lead Compliance: No
• Nominal Size: 1-1/4 in
• Pressure Class: 300 Lb
• Inlet to Outlet Length: 4.5
• Media: STEAM
• Temperature Rating: -20 to 406 deg F
• Trim Material: Bronze
• Type: Y-Pattern
• Category: Check Valves
• Flow Coefficient (cv): 39
• Min. Temp.: -20 00b0F
• Pipe Size: 1 1/4"
