Conbraco 40-XT5-04 Expansion Tank 10 Gallon Lead-Free

Product Description

The Conbraco 40-XT5-04 is an expansion tank designed for potable water systems. It features a capacity of ten gallons and supports a pressure rating of one hundred fifty PSI. The tank is constructed from drawn steel and is lead-free, ensuring safe usage in various applications. This model can be positioned horizontally or vertically.

• Ten-gallon capacity
• Field adjustable air charge
• Designed for both horizontal and vertical installation

Product Highlights

This expansion tank helps protect closed water supply systems from thermal expansion. It is suitable for domestic hot water systems and is compliant with NSF/ANSI standards.

Product Information

Standard Information

• Manufacturer: Conbraco
• Type: Horizontal/Vertical

Technical Specifications

• Inlet/Outlet Connection: 3/4 Inch Threaded
• Tank Material: Drawn Steel
• Temperature Rating: 200 Deg F
• Air Charge Capacity: 35 PSIG
• Expansion Volume: 5.2 Gallon
• Tank Dimensions: 11.5 Inch Diameter x 20 Inch Height
• Tank Warranty: 5 Year
• Applicable Standards: NSF/ANSI 61/372, IAPMO, UPC
