Conbraco 30LF-037-01 1-1/2 NPT x NPT Lead-Free Bronze Gate Valve

Product Description

The Conbraco 30LF-037-01 is a lead-free gate valve designed for use in various plumbing applications. This valve connects through NPT threads and supports a pressure rating of one hundred twenty-five PSI SWP and two hundred PSI CWP. It is constructed from C89836 bronze for durability and reliability.

• Nominal size: one and one-half inch
• End connection: threaded x threaded
• Fully ported design for maximum flow

Product Highlights

This gate valve is suitable for commercial and potable water applications. It features adjustable graphite stem packing and meets multiple industry standards, ensuring safe and efficient operation.

Product Information

Standard Information

• Manufacturer: Conbraco
• UPC: 67075068692

Technical Specifications

• Body Material: ASTM B584 C89836 Bronze
• Bonnet Material: ASTM B584 C89836 Bronze
• Temperature Rating: -20 to 406 Deg F
• Pressure Rating: 125 PSI SWP, 200 PSI CWP
• Application: Commercial, Potable Water
• Applicable Standard: CSA B51, NSF/ANSI 61/372, MSS SP-80/139, ISO, ASME B1.20.1, CRN 0C14667.5, ARRA
• Seal Material: Grafoil
• Wedge Material: ASTM B584 C89836 Bronze
