Apollo Valves 30LF-035-01 1 Inch Full Port Gate Valve Lead-Free 125 PSI SWP 200 PSI CWP Replacement 102T1-LF

Product Description

The Apollo Valves model 30LF-035-01 offers reliable control in fluid handling systems. Featuring a lead-free construction with durable bronze components, this gate valve is suitable for commercial water applications.

• Lead-free, solid wedge disc gate valve with non-rising stem and full port design.
• Equipped with a robust handwheel mechanism for manual control.
• Designed for use in systems with up to 200 PSI CWP.

Product Highlights

Rated for 125 PSI SWP and 200 PSI CWP, this valve ensures optimal performance in a variety of settings, including potable water systems. The bronze build provides corrosion resistance and longevity.

Product Information

Standard Information

• Manufacturer: Apollo Valves
• SKU: 30LF-035-01
• UPC: 8473810005
• UNSPSC: 40141613

Technical Specifications

• Body Material: ASTM B584 C89836 Bronze
• Stem Material: ASTM B21 UNS C46400 Brass
• Seat Material: ASTM B21 UNS C46400 Brass
• Seal Material: Grafoil
• Temperature Rating: -20 to 406 Deg F
• Flow Rate: 72.3 Cv
• Connection Type: NPT x NPT
• Standards: CSA B51, NSF/ANSI 61/372, MSS SP-80/139, ISO, ASME B1.20.1, CRN 0C14667.5, ARRA compliant
