Conbraco 30LF-032-01 3/8 NPT x NPT Gate Valve 125 PSI SWP

Product Description

The Conbraco 30LF-032-01 is a gate valve designed for various plumbing applications. It features a nominal size of three-eighths inches and comes with a threaded x threaded end connection. The valve is made from lead-free bronze, ensuring safety in potable water applications.

• Non-rising stem with handwheel actuation.
• Pressure rating up to 125 PSI SWP and 200 PSI CWP.
• Temperature rating from minus twenty to four hundred six degrees Fahrenheit.

Product Highlights

This gate valve is suitable for commercial use and complies with standards like CSA B51 and NSF/ANSI 61/372. It has adjustable graphite stem packing for enhanced performance.

Product Information

Standard Information

• Manufacturer: Conbraco
• Type: Domestic, Solid Wedge Disc, Full Port

Technical Specifications

• Body Material: ASTM B584 C89836 Bronze
• Bonnet Material: ASTM B584 C89836 Bronze
• Handle Material: Malleable Iron
• Seat Material: ASTM B21 UNS C46400 Brass
• Stem Material: ASTM B21 UNS C46400 Brass
• Wedge Material: ASTM B584 C89836 Bronze
• Seal Material: Grafoil
• Flow Rate: 6 Cv
• End To End Distance: 1.76 inches
