Apollo Valves 30-045-01 Gate Valve 1 Inch - Full Port Solid Wedge Disc

Product Description

The Apollo Valves model 30-045-01 is a robust gate valve designed for commercial applications. Crafted from high-quality ASTM B62 bronze, this valve ensures reliable operation and durability. Its full port design with a solid wedge disc offers optimal flow capabilities in a variety of plumbing and heating applications.

• Features a non-rising stem with female soldered connections.
• Pressure rating up to 200 PSI at 100 degrees Fahrenheit.
• Equipped with a rugged malleable iron handwheel for easy operation.

Product Highlights

This gate valve is ideal for non-potable water use, offering a secure, leak-proof seal with its asbestos-free Grafoil and guided solid bronze disc wedge. It's designed to be dezincification resistant, adding to its longevity and structural integrity.

Product Information

Standard Information

• Material: Body, stem, wedge, and bonnet made from ASTM B62 Bronze.
• Design: Full Port, Solid Wedge Disc.
• Temperature Capability: Suitable for temperatures ranging from -20 to 406 degrees Fahrenheit.

Technical Specifications

• Nominal Size: 1 Inch x 1 Inch.
• Pressure Rating: Class 125, 200 PSI at 100 Deg F CWP.
• Standards: Meets MSS-SP-80, CRN 0C14667.
• Flow Capacity: 72.3 GPM.
