Conbraco 10-608-10 2 FPT x FPT 50 PSIG Bronze Safety Relief Valve

Product Description

The Conbraco 10-608-10 is a safety relief valve designed to efficiently manage pressure in plumbing systems. This valve features a two-inch inlet and outlet, both with female threaded connections. Constructed from ASTM B584 bronze, it is suitable for various applications, including hot water heating and commercial supply systems.

• Inlet and outlet sizes of two inches.
• Set pressure range of fifty PSIG.
• Temperature rating of two hundred fifty degrees Fahrenheit.

Product Highlights

This safety relief valve prevents overpressure in systems by releasing excess pressure when necessary. It is constructed with a corrosion-resistant design and includes features like a silicone seat and a diaphragm rivet made of aluminum.

Product Information

Standard Information

• Manufacturer: Conbraco
• UPC: 670750879524

Technical Specifications

• Body Material: ASTM B584 Bronze
• Spring Material: Steel Alloy Plated
• Seat Material: Silicone
• Disc Material: ASTM B16 Brass
• Set Pressure Range: 50 PSIG
• Temperature Rating: 250 Deg F
• End Connection: Female Threaded x Female Threaded
• Size: 7.2 Inch Width x 14 Inch Height
