Apollo PWR7481463 Powerpress Gas Elbow 2 inch x 2 inch Press x Press 90 Degree

Product Description

The Apollo Powerpress PWR7481463 is a two-inch elbow fitting designed for gas applications. It features a press connection system made of carbon steel with a zinc nickel coating for corrosion resistance. This product allows for a secure connection with a 90-degree angle, suitable for various piping installations.

• Connection Type: Press x Press
• Material: Carbon Steel with Zinc Nickel Coating
• Pressure Rating: 125 PSI, Temperature Range: -40 to 194 Deg F

Product Highlights

This fitting provides reliable performance in fuel gas applications, ensuring secure and effective piping connections.

Product Information

Standard Information

• Manufacturer: Apollo
• MPN: PWR7481463

Technical Specifications

• Connection Size: 2 inches
• Angle: 90 Degrees
• End Connection: Press x Press
• Material Specification: ASTM A106
• Pressure Rating: 125 PSI
• Temperature Rating: -40 to 194 Deg F
• Applicable Standards: CSA LC-4, IAPMO LC-4, CRN, UPC, IPC, IFGC, ASME B31.1/B31.3/B31.5/B31.9
• Includes: HNBR Sealing Element, Yellow Visual Control Ring
