Apollo Powerpress 7483181 Gas Reduced Coupling 1 inchesx3/4 inches

Product Description

The APOLLO POWERPRESS 7483181 is a reducer designed for gas applications using thick wall steel pipe. This PowerPress Gas system reduces installation times and ensures a clean working environment. It features a DW-profile press fitting suitable for sizes 1/2" up to 2". The fitting is zinc-nickel plated carbon steel with HNBR sealing.

• Outstanding corrosion resistance due to ZnNi coating
• Clear identification of materials and dimensions
• Visu-Control-ring and Leak Before Pressed-function

Product Highlights

The Apollo PowerPress system provides fast connections and a visual press indicator for reliable performance. Suitable for use with Schedule 10 through 40 thick wall steel pipe.

Product Information

Standard Information

• Brand: APOLLO POWERPRESS
• Manufacturer Part Number: 7483181
• Country of Origin: Netherlands

Technical Specifications

• d1: 33.7
• DN1: 1"
• l1: 39
• z1: 3
• d2: 26.9
• DN2: 3/4"
• l2: 31
• z2: 0
• article number with gtin: PWR7483181 (08711985469615)
• product number with gtin: PWR7483181 (08711985467437)
• manufacturer: Aalberts integrated piping systems B.V. (VSH)
• size: 1"x3/4"
• materials: steel (St 35 (1.0308))
• finishing: zinc-nickel plated
• shape: straight, reducer
• connection type: press (DW), press (DW)
• pressure rating (PN): PN 5
• sealing: HNBR
• min. medium temperature: -40 °F
• max medium temperature: 194 °F
• brand: Apollo
• series: PowerPress Gas
• product type: 420G
• Material connection 1: Steel
• Material quality connection 1: St 35 (1.0308)
• Surface protection connection 1: Zinc/nickel
• Material connection 2: Steel
• Material quality connection 2: St 35 (1.0308)
• Surface protection connection 2: Zinc/nickel
• Shape: Straight
• Model: 1-part
• Reducing: Yes
• Eccentric: No
• System specific: Yes
• Nominal diameter connection 1: DN 25
• Outer pipe diameter connection 1: 33.7mm
• Outer pipe diameter connection 1 (imperial): 1.33"
• Wall thickness, connection 1: 2.9mm
• Wall thickness, connection 1 (imperial): 0.11"
• Connection 1: Press sleeve
• Contour code connection 1: DW
• Nominal diameter connection 2: DN 20
• Outer pipe diameter connection 2: 26.9mm
• Outer pipe diameter connection 2 (imperial): 1.06"
• Wall thickness, connection 2: 2.7mm
• Wall thickness, connection 2 (imperial): 0.11"
• Connection 2: Press sleeve
• Contour code connection 2: DW
• Main colour fitting: Grey
• Material sealing: Hydrogenated acrylonitrile butadiene rubber (HNBR)
• With buffer stud: Yes
• High tensile strength: Yes
• Length: 71mm
• Length (imperial): 2.8"
• Length of connection 1: 39.4mm
• Length of connection 1 (imperial): 1.55"
• Working length connection 1: 3.4mm
• Working length connection 1 (imperial): 0.13"
• Length of connection 2: 31.4mm
• Length of connection 2 (imperial): 1.24"
• Working length connection 2: 0.4mm
• Working length connection 2 (imperial): 0.02"
• Medium temperature (continuous): -40°C - 90°C
• Medium temperature (continuous) (imperial): -40°F - 194°F
• With thermal insulation: No
• With sealing rings/gaskets: No
• Capped: Yes
• With connection indicator: Yes
• With drain valve: No
• With de-aerator: No
• FM quality mark: No
• LPCB quality mark: No
• ULC quality mark: No
• UL quality mark: No
• DIN-CERTCO certificate: No
• VdS quality mark: No
• With approval for TÜV: No
• DVGW quality mark for gas: No
• DVGW quality mark for water: No
• Certified according to NF 545: No
• KIWA certified: No
• Gastec QA mark: No
• KOMO certified: No
• Gastec QA - AR 214 (H2): No
• Type approval according to BBR/EKS: No
• Fitting / Connector Type: Coupling
• Nominal Size: 1 x 3/4 in
• Suitable For Use With: HNBR (Gas)
• Manufacturer #: PWR7483181
• Material: Carbon Steel
• Series: 401RG
• Temperature Rating: -40 deg F to 194 deg F
• ASME: ASME B31.1, ASME B31.3, ASME B31.5, ASME B31.9
• Clean Bagged: No
• Coating: Zinc Nickel
• Collection: Model 420G
• End Connection 1: Press
• End Connection 2: Press
• End Connections: Press
• FM Approved: No
• Fitting Size 1: 1
• Fitting Size 2: 3/4
• Fitting Sizes: 1 in x 3/4 in
• Fitting Type: Coupling, Reducing
• IAPMO Listed: Yes
• Pressure Class: 125#
• Schedule Class: 40
• UL Listed: No
• End Style: P x P
• Nominal Diameter Connection 1: DN 25
• Nominal Diameter Connection 2: DN 20
