Apollo Powerpress 7483168 gas reduced coupling 3/4 inchesx1/2 inches

Product Description

The Apollo PowerPress 7483168 420G is a reducer for gas applications, designed for thick wall steel pipe. Apollo PowerPress Gas system installation times are reduced significantly and a clean working environment is assured. It consists of DW-profile press fittings and valves in sizes 3/4"x1/2".

• Outstanding corrosion resistance due to ZnNi coating
• Clear identification of materials and dimensions
• Visu-Control-ring and Leak Before Pressed-function

Product Highlights

This reducer ensures secure gas connections with its carbon steel construction and press end style, suitable for residential, commercial, and industrial applications.

Product Information

Standard Information

• Brand: APOLLO POWERPRESS
• Manufacturer Part Number: 7483168
• Country of Origin: Netherlands

Technical Specifications

• DN1: 3/4"
• DN2: 1/2"
• Article number with gtin: PWR7483168 (08711985467413)
• Product number with gtin: PWR7483168 (08711985467413)
• Manufacturer: Aalberts integrated piping systems B.V. (VSH)
• Item group: 420G 420G - Apollo PowerPress Gas reducer (2 x press)
• Size: 3/4"x1/2"
• Materials: steel (St 35 (1.0308))
• Finishing: zinc-nickel plated
• Shape: Straight
• Connection type: press (DW), press (DW)
• Pressure rating (PN): PN 5
• Sealing: HNBR
• Min. medium temperature: -40 °F
• Max medium temperature: 194 °F
• Product group: fittings
• ETIM class: EC003024 Fitting with 2 connections
• Intrastat code: 73079980
• Brand: Apollo
• Series: PowerPress Gas
• Product type: 420G
• UNSPS: 40173602
• SCIP: d30775b1-132f-4657-80d3-acc91bda76c2
• Material connection 1: Steel
• Material quality connection 1: St 35 (1.0308)
• Surface protection connection 1: Zinc/nickel
• Material connection 2: Steel
• Material quality connection 2: St 35 (1.0308)
• Surface protection connection 2: Zinc/nickel
• Model: 1-part
• Reducing: Yes
• Eccentric: No
• System specific: Yes
• Nominal diameter connection 1: DN 20
• Outer pipe diameter connection 1: 26.9mm
• Outer pipe diameter connection 1 (imperial): 1.06"
• Wall thickness, connection 1: 2.7mm
• Wall thickness, connection 1 (imperial): 0.11"
• Connection 1: Press sleeve
• Contour code connection 1: DW
• Nominal diameter connection 2: DN 15
• Outer pipe diameter connection 2: 21.3mm
• Outer pipe diameter connection 2 (imperial): 0.84"
• Wall thickness, connection 2: 2.7mm
• Wall thickness, connection 2 (imperial): 0.11"
• Connection 2: Press sleeve
• Contour code connection 2: DW
• With buffer stud: Yes
• High tensile strength: Yes
• Medium temperature (continuous): -40°C - 90°C
• Medium temperature (continuous) (imperial): -40°F - 194°F
• With thermal insulation: No
• With sealing rings/gaskets: No
• Capped: Yes
• With connection indicator: Yes
• With drain valve: No
• With de-aerator: No
• FM quality mark: No
• LPCB quality mark: No
• ULC quality mark: No
• UL quality mark: No
• DIN-CERTCO certificate: No
• VdS quality mark: No
• With approval for TÜV: No
• DVGW quality mark for gas: No
• DVGW quality mark for water: No
• Certified according to NF 545: No
• KIWA certified: No
• Gastec QA mark: No
• KOMO certified: No
• Gastec QA - AR 214 (H2): No
• Type approval according to BBR/EKS: No
• Fitting Size 1: 3/4
• Fitting Size 2: 1/2
• Fitting Sizes: 3/4 in x 1/2 in
• Fitting Type: Coupling, Reducing
• Material: Carbon Steel, Rubber
• Material Type: HNBR
• Maximum Temperature: 194
• Pressure Class: 125#
• Schedule Class: 40
• d1: 26.9
• l1: 34
• z1: 3
• d2: 21.3
• l2: 29
• z2: 1
• Length: 63mm
• Length (imperial): 2.48"
• Length of connection 1: 33.9mm
• Length of connection 1 (imperial): 1.33"
• Working length connection 1: 2.9mm
• Working length connection 1 (imperial): 0.11"
• Length of connection 2: 28.9mm
• Length of connection 2 (imperial): 1.14"
• Working length connection 2: 0.9mm
• Working length connection 2 (imperial): 0.04"
• ASME: ASME B31.1, ASME B31.3, ASME B31.5, ASME B31.9
• Coating: Zinc Nickel
• Collection: Model 420G
• End Connection 1: Press
• End Connection 2: Press
• End Connections: Press
• IAPMO Listed: Yes
• Origin: Global
