Apollo Powerpress 7482475 Gas Stop End F 1/2 inches

Product Description

The Apollo PowerPress 7482475 417G is an end cap designed for gas applications and thick wall steel pipe. The Apollo PowerPress system significantly reduces installation times and ensures a clean working environment. It features DW-profile press fittings and valves in sizes 1/2" up to and including 2".

• Outstanding corrosion resistance due to ZnNi coating
• Clear identification of materials and dimensions
• Visu-Control-ring and Leak Before Pressed-function

Product Highlights

This cap offers simple, fast connections and compact fittings for recessed work. It features a visual press indicator and Leak Before Press functionality.

Product Information

Standard Information

• Brand: APOLLO POWERPRESS
• Manufacturer Part Number: 7482475
• Country of Origin: Netherlands

Technical Specifications

• d1: 21.3
• DN1: 1/2"
• l1: 35
• z1: 7
• ETIM class: EC003023 Fitting with 1 connection
• Material connection 1: Steel
• Material quality connection 1: St 35 (1.0308)
• Surface protection connection 1: Zinc/nickel
• System specific: Yes
• Nominal diameter connection 1: DN 15
• Outer pipe diameter connection 1: 21.3mm
• Outer pipe diameter connection 1 (imperial): 0.84"
• Wall thickness, connection 1: 2.7mm
• Wall thickness, connection 1 (imperial): 0.11"
• Connection 1: Press sleeve
• Contour code: DW
• Material sealing: Hydrogenated acrylonitrile butadiene rubber (HNBR)
• Main colour fitting: Grey
• Length of connection 1: 35mm
• Length of connection 1 (imperial): 1.38"
• Working length connection 1: 7mm
• Working length connection 1 (imperial): 0.28"
• Medium temperature (continuous): -40°C - 90°C
• Medium temperature (continuous) (imperial): -40°F - 194°F
• With sealing rings/gaskets: No
• With drain valve: No
• With de-aerator: No
• Capped: Yes
• With connection indicator: Yes
• Fitting / Connector Type: Cap
• Nominal Size: 1/2 in
• Suitable For Use With: HNBR (Gas)
• Manufacturer: Apollo Conbraco
• Manufacturer #: PWR7482475
• Material: Carbon Steel
• Series: 417G
• Application: Gas
• Coating: Zinc Nickel, Galvanized
• Collection: 417G Series
• End Connection 1: Press
• End Connections: Press
• Fitting Size 1: 1/2
• Fitting Sizes: 1/2 in
• Fitting Type: Cap
• Material Type: HNBR
• Maximum Temperature: 302
• Origin: Global
• Pressure Class: 200 psi
• Seal Material: HNBR
• Shape: End Coupling
• Size: 1/2"
• Wall Thickness Connection 1: 2.7 mm
• Working Length Connection 1: 7/25"
• End Style: Press x Cap
• Grade: Grade St 35
• Nominal Dia.: 15 mm
