Apollo Powerpress 7482081 Gas Straight Connector FM 1/2 inchesxMPT1/2 inches

Product Description

The APOLLO POWERPRESS 7482081 is a male thread adapter designed for gas applications using thick wall steel pipe. This system significantly reduces installation times and ensures a clean working environment. It features DW-profile press fittings and valves in sizes from 1/2" up to 2".

• Outstanding corrosion resistance due to ZnNi coating.
• Clear identification of materials and dimensions.
• Visu-Control-ring and Leak Before Pressed-function.

Product Highlights

This gas straight connector offers quick installation and corrosion resistance for gas applications using steel pipe.

Product Information

Standard Information

• Brand: APOLLO POWERPRESS
• Manufacturer Part Number: 7482081
• Country of Origin: Netherlands

Technical Specifications

• d1: 21.3
• DN1: 1/2"
• l1: 35
• z1: 7
• d2: 21.3
• DN2: 1/2"
• l2: 15
• slw0: 28
• h: 9
• Article: Apollo PowerPress Gas straight connector FM 1/2"xMPT1/2"
• Manufacturer: Aalberts integrated piping systems B.V. (VSH)
• Item group: 404G 404G - Apollo PowerPress Gas male thread adapter (press x male thread)
• Size: 1/2” x MPT1/2
• Material connection 1: Steel
• Material quality connection 1: St 35 (1.0308)
• Surface protection connection 1: Zinc/nickel
• Material connection 2: Steel
• Material quality connection 2: St 35 (1.0308)
• Surface protection connection 2: Zinc/nickel
• Shape: straight
• Model: 1-part
• Reducing: No
• Eccentric: No
• System specific: Yes
• Nominal diameter connection 1: DN 15
• Outer pipe diameter connection 1: 21.3mm
• Outer pipe diameter connection 1 (imperial): 0.84"
• Wall thickness, connection 1: 2.7mm
• Wall thickness, connection 1 (imperial): 0.11"
• Connection 1: Press sleeve
• Contour code connection 1: DW
• Nominal diameter connection 2: 1/2 inch (15)
• Outer pipe diameter connection 2: 21.3mm
• Outer pipe diameter connection 2 (imperial): 0.84"
• Connection 2: External thread conical (NPT)
• Main colour fitting: Grey
• Material sealing: Hydrogenated acrylonitrile butadiene rubber (HNBR)
• With buffer stud: Yes
• High tensile strength: Yes
• Length: 54mm
• Length (imperial): 2.13"
• Length of connection 1: 35mm
• Length of connection 1 (imperial): 1.38"
• Working length connection 1: 7mm
• Working length connection 1 (imperial): 0.28"
• Length of connection 2: 15.4mm
• Length of connection 2 (imperial): 0.61"
• Wrench width: 28mm
• Wrench width (imperial): 1.1"
• Medium temperature (continuous): -40°C - 90°C
• Medium temperature (continuous) (imperial): -40°F - 194°F
• With thermal insulation: No
• With sealing rings/gaskets: No
• Capped: Yes
• With connection indicator: Yes
• With drain valve: No
• With de-aerator: No
• FM quality mark: No
• LPCB quality mark: No
• ULC quality mark: No
• UL quality mark: No
• DIN-CERTCO certificate: No
• VdS quality mark: No
• With approval for TÜV: No
• DVGW quality mark for gas: No
• DVGW quality mark for water: No
• Certified according to NF 545: No
• KIWA certified: No
• Gastec QA mark: No
• KOMO certified: No
• Gastec QA - AR 214 (H2): No
• Type approval according to BBR/EKS: No
• Materials: steel (St 35 (1.0308))
• Finishing: zinc-nickel plated
• Connection type: press (DW), MPT - male thread conical (NPT)
• Pressure rating (PN): PN 5
• Sealing: HNBR
• Technical min. medium temperature: -40 °F
• Technical max medium temperature: 194 °F
• Product group: fittings
• ETIM class: EC003024 Fitting with 2 connections
• Intrastat code: 73079980
• Country of origin: Netherlands
• Brand: APOLLO VALVES
• Series: PowerPress Gas
• Product type: 404G
• UNSPSC: 40172502
• SCIP: d30775b1-132f-4657-80d3-acc91bda76c2
• Clean Bagged: No
• Collection: 404G Series
• End Connection 1: Press
• End Connection 2: MPT
• End Connections: Press x MPT
• FM Approved: No
• Fitting Size 1: 1/2
• Fitting Size 2: 1/2
• Fitting Sizes: 1/2 in
• Fitting Type: Adapter, Straight
• IAPMO Listed: No
• Material: Carbon Steel, Rubber
• Material Type: HNBR
• Maximum Temperature: 194
• NSF Certified: No
• Origin: Global
• Pressure - Maximum: 200 psi
• UL Listed: No
• UPC: 670750894978
• MPN: PWR7482081
• Category: Business & Industrial
