Apollo Powerpress 7481716 Gas Reduced T-Piece FFF 3/4 inchesx3/4 inchesx1/2 inches

Product Description

The APOLLO POWERPRESS 7481716 is a T-piece for natural gas applications, designed for thick wall steel pipe. By using Apollo PowerPress system installation times are reduced significantly. It features a Visu-Control-ring and Leak Before Pressed-function. It is designed to be used with Schedule 10 through 40 thick wall steel pipe for sizes ranging from 1/2 through 2.

• Outstanding corrosion resistance due to ZnNi coating
• Clear identification of materials and dimensions
• Visu-Control-ring and Leak Before Pressed-function

Product Highlights

The Apollo PowerPress system offers simple, fast connections with compact fittings. It features a visual press indicator and clear material identification.

Product Information

Standard Information

• Brand: APOLLO POWERPRESS
• Manufacturer Part Number: 7481716
• Country of Origin: Netherlands

Technical Specifications

• label: d1
• value: 26.7
• DN1: 3/4"
• l1: 57
• z1: 26
• d2: 21.3
• DN2: 1/2"
• l2: 56
• z2: 28
• d3: 26.7
• DN3: 3/4"
• l3: 57
• z3: 26
• etim-class: EC003025 Fitting with 3 connections
• Material connection 1: Steel
• Material quality connection 1: St 35 (1.0308)
• Surface protection connection 1: Zinc/nickel
• Material connection 2: Steel
• Material quality connection 2: St 35 (1.0308)
• Surface protection connection 2: Zinc/nickel
• Material connection 3: Steel
• Material quality connection 3: St 35 (1.0308)
• Surface protection connection 3: Zinc/nickel
• Model: T-piece
• Angle: 90
• Reducing: Yes
• Multi-part: No
• System specific: Yes
• Nominal diameter connection 1: DN 20
• Outer pipe diameter connection 1: 26.7mm
• Outer pipe diameter connection 1 (imperial): 1.05"
• Wall thickness, connection 1: 2.7mm
• Wall thickness, connection 1 (imperial): 0.11"
• Connection 1: Press sleeve
• Contour code connection 1: DW
• Nominal diameter connection 2: DN 15
• Outer pipe diameter connection 2: 21.3mm
• Outer pipe diameter connection 2 (imperial): 0.84"
• Wall thickness, connection 2: 2.7mm
• Wall thickness, connection 2 (imperial): 0.11"
• Connection 2: Press sleeve
• Contour code connection 2: DW
• Nominal diameter connection 3: DN 20
• Outer pipe diameter connection 3: 26.7mm
• Outer pipe diameter connection 3 (imperial): 1.05"
• Wall thickness, connection 3: 2.7mm
• Wall thickness, connection 3 (imperial): 0.11"
• Connection 3: Press sleeve
• Contour code connection 3: DW
• Material sealing: Hydrogenated acrylonitrile butadiene rubber (HNBR)
• Main colour fitting: Grey
• Length of connection 1: 57mm
• Length of connection 1 (imperial): 2.24"
• Working length connection 1: 26mm
• Working length connection 1 (imperial): 1.02"
• High tensile strength: Yes
• Length of connection 2: 55.5mm
• Length of connection 2 (imperial): 2.19"
• Working length connection 2: 27.5mm
• Working length connection 2 (imperial): 1.08"
• Length of connection 3: 57mm
• Length of connection 3 (imperial): 2.24"
• Working length connection 3: 26mm
• Working length connection 3 (imperial): 1.02"
• Medium temperature (continuous): -40 - 90
• Medium temperature (continuous) (imperial): -40 - 194
• With sealing rings/gaskets: No
• With drain valve: No
• With de-aerator: No
• With thermal insulation: No
• With buffer stud: Yes
• Capped: Yes
• With connection indicator: Yes
• FM quality mark: No
• LPCB quality mark: No
• ULC quality mark: No
• UL quality mark: No
• VdS quality mark: No
• DVGW quality mark for gas: No
• DVGW quality mark for water: No
• KIWA certified: No
• Gastec QA mark: No
• KOMO certified: No
• Gastec QA - AR 214 (H2): No
• Fitting / Connector Type: Tee
• Nominal Size: 3/4 x 3/4 x 1/2 in
• Suitable For Use With: HNBR (Gas)
• Manufacturer: Apollo Conbraco
• Manufacturer #: PWR7481716
• Material: Carbon Steel
• Series: 411RG
• Brand: APOLLO VALVES
• MPN: PWR7481716
• UPC: Does Not Apply
• Condition: New
• Connection Type: Press x Press x Press
• End Style: P x P x P
