Apollo Powerpress 7481507 Gas Bend 90° 1-1/4 inch

Product Description

The APOLLO POWERPRESS 7481507 is a 90° bend designed for gas applications using thick wall steel pipe. The Apollo PowerPress system reduces installation times and ensures a clean working environment. It features DW-profile press fittings and valves in sizes from 1/2" up to 2".

• Outstanding corrosion resistance due to ZnNi coating
• Clear identification of materials and dimensions
• Visu-Control-ring and Leak Before Pressed-function

Product Highlights

This gas bend is designed for fast connections and recessed work, featuring a visual inspection ring and HNBR sealing element.

Product Information

Standard Information

• Brand: APOLLO POWERPRESS
• Manufacturer Part Number: 7481507
• Country of Origin: Netherlands

Technical Specifications

• d1: 42.2
• DN1: 1-1/4"
• l1: 97
• z1: 49
• d2: 42.2
• DN2: 1-1/4"
• l2: 109
• radius: 45
• Angle: 90
• ETIM class: EC003024 Fitting with 2 connections
• Material connection 1: Steel
• Material quality connection 1: St 35 (1.0308)
• Surface protection connection 1: Zinc/nickel
• Material connection 2: Steel
• Material quality connection 2: St 35 (1.0308)
• Surface protection connection 2: Zinc/nickel
• Shape: Bend
• Model: 1-part
• Bend angle: 90°
• Bend radius: 45mm
• Bend radius (imperial): 1.77"
• Reducing: No
• Eccentric: No
• System specific: Yes
• Nominal diameter connection 1: DN 32
• Outer pipe diameter connection 1: 42.2mm
• Outer pipe diameter connection 1 (imperial): 1.66"
• Wall thickness, connection 1: 2.9mm
• Wall thickness, connection 1 (imperial): 0.11"
• Connection 1: Press sleeve
• Contour code connection 1: DW
• Nominal diameter connection 2: DN 32
• Outer pipe diameter connection 2: 42.2mm
• Outer pipe diameter connection 2 (imperial): 1.66"
• Connection 2: Soldered end
• Main colour fitting: Grey
• Material sealing: Hydrogenated acrylonitrile butadiene rubber (HNBR)
• With buffer stud: Yes
• High tensile strength: Yes
• Medium temperature (continuous): -40°C - 90°C
• Medium temperature (continuous) (imperial): -40°F - 194°F
• With thermal insulation: No
• With sealing rings/gaskets: No
• Capped: Yes
• With connection indicator: Yes
• With drain valve: No
• With de-aerator: No
• FM quality mark: No
• LPCB quality mark: No
• ULC quality mark: No
• UL quality mark: No
• DIN-CERTCO certificate: No
• VdS quality mark: No
• With approval for TÜV: No
• DVGW quality mark for gas: No
• DVGW quality mark for water: No
• Certified according to NF 545: No
• KIWA certified: No
• Gastec QA mark: No
• KOMO certified: No
• Gastec QA - AR 214 (H2): No
• Type approval according to BBR/EKS: No
• Length: 118mm
• Length (imperial): 4.65"
• Length of connection 1: 96.5mm
• Length of connection 1 (imperial): 3.8"
• Working length connection 1: 48.5mm
• Working length connection 1 (imperial): 1.91"
• Length of connection 2: 108.5mm
• Length of connection 2 (imperial): 4.27"
• Brand: Apollo
• Material: Steel
• Fitting/Connector Type: 90 deg Elbow
• Nominal Size: 1-1/4 in
• End Style: POWERPRESS x Male
• Series: 407-2G
• Product Type: Elbow Fitting
• Finish: Gray
• Collection: PowerPress Gas
• Applications: Natural Gas, Compressed Air
• Approvals: CSA LC-4, ICC LC4, IAPMO LC-4, CRN
• Sealing: HNBR
• Segments: Industry, Commercial Building
• Style: 1-Part
• Volume: 0.89 Litre
