Apollo Conbraco Industries 7714427 BV,3/4NPT,FP,BRZ,LTCH,SS B&S

Product Description

Apollo Conbraco Industries 7714427 is a two-piece ball valve designed for reliable performance in various fluid handling applications. It features a three-quarter inch nominal size with FNPT end style, suitable for up to six hundred psi CWP pressure and a temperature rating of five hundred degrees Fahrenheit. This valve is engineered with a latch-lock lever actuator, providing ease of operation and control.

• 316 stainless steel ball enhances durability
• Bronze body ensures corrosion resistance
• Full port design allows for unrestricted flow

Product Highlights

This ball valve is specifically built for domestic use, featuring a blow-out proof stem design, hardened ball for wear resistance, and is 100% factory tested for quality assurance.

Product Information

Standard Information

• Manufacturer: Apollo Conbraco Industries
• Type: Two-Piece

Technical Specifications

• Actuator Type: Latch-Lock Lever
• Ball Material: 316 Stainless Steel
• Body Material: Bronze
• End Style: FNPT
• Nominal Size: 3/4 inch
• Orifice Size: 3/4 inch
• Port Type: Full
• Pressure Rating: 600 psi CWP
• Temperature Rating: 500 degrees Fahrenheit
• Inlet to Outlet Length: 3.12 inches
• Top to Inlet Center: 2.12 inches
• Softgoods Material: PTFE/RPTFE
• Trim Material: 316 Stainless Steel Stem/RPTFE Seat
