Apollo AP-RT-3000-P RT-3000 Weatherproof Duct Smoke Detector Photoelectric

Product Description

The APOLLO AP-RT-3000-P photoelectric weather tight duct smoke detector reduces the total cost of ownership. The weathertight NEMA 4X rated corrosion resistant enclosure coupled with extended temperature listings allow installation in the widest possible range of indoor/outdoor environments. Works with APC remote accessories and is compatible with building automation and fire alarm systems.

• 180 visibility for all visual indicators with cover in place
• NEMA 4X watertight enclosure for non-hazardous indoor and outdoor Applications, to include corrosive environments
• Patented cover tether retains the one-piece cover at unit

Product Highlights

The detector features a flashing LED that indicates normal operation, viewable with the cover on. It also has a patented test port that allows for aerosol smoke testing without cover removal.

Product Information

Standard Information

• Brand: APOLLO
• Manufacturer Part Number: AP-RT-3000-P
• Country of Origin: USA

Technical Specifications

• Detector Used: 65A Photoelectric Detector
• Status Indicator ">– Alarm: Red
• Status Indicator ">– Fault: Yellow
• Humidity (Min): 10% RH
• Humidity (Max): 93% RH
• Humidity Note: no condensation or icing
• Humidity: 10% to 93% (no condensation or icing)
• Standards: UL 268A, ULC-S529
• Materials Housing: Polycarbonate
• Detection Principle: Photo-electric light scattering.
• Number Of Sampling Pipe Inlets: 1
• Exhaust Airpipe Outlet: 18.8mm
• Housing Type: NEMA 4X, Weathertight, corrosive resistant
