Apollo 86B10301 BV,1/2NPT,CL600,3PC,SS

Product Description

Apollo, 86B10301, is a ball valve designed for reliable flow control. It features a three-piece construction with a nominal size of one-half inch and FNPT end style. This valve operates with a lever actuator and is constructed for a pressure rating of two hundred fifty psi and a class of six hundred pounds. The inlet to outlet length measures two point eight inches with a top to inlet center distance of three point zero two inches. It is made from stainless steel with PTFE soft goods.

• Three-piece design for durability
• Lever operated actuator for easy handling
• Full port for maximum flow capacity

Product Highlights

This valve is ideal for use in various industrial applications where reliable performance is required.

Product Information

Standard Information

• Manufacturer: Apollo Conbraco Industries
• UPC: 670750059872

Technical Specifications

• Actuator Type: Lever Operated
• Ball Material: Stainless Steel
• Body Material: Stainless Steel
• Domestic/Import: Domestic
• End Style: FNPT
• Inlet to Outlet Length: 2.8 inches
• Nominal Size: 1/2 inch
• Port Type: Full
• Pressure Class: 600 lb
• Pressure Rating: 250 psi SWP
• Series: 86B-100
• Softgoods Material: PTFE
• Top to Inlet Center: 3.02 inches
• Trim Material: 316 Stainless Steel
• Type: 3-Piece
