Apex PS1806N Long Tape Measure 100 Ft Steel Blade

Product Description

The APEX PS1806N is a 100-foot long tape measure built for trade professionals who need reliable linear measurement on the job. The blade is made from steel with a Yellow Ny-Clad finish, which provides corrosion resistance and blade longevity under field conditions. At 0.5 inches wide with an E4 blade style, the tape offers the rigidity needed for extended reach without excessive blade curl. Measurements are in SAE (imperial) units. This is a manual-lock tape — there is no auto-lock mechanism — making it a straightforward pull-and-read tool suited for layout, rough framing, pipe runs, duct routing, and general trade measurement tasks.

The PS1806N is used wherever a long-format tape is required: commercial construction, HVAC layout, electrical conduit runs, plumbing rough-in, and site survey work. The 100-foot blade length makes it practical for measuring room dimensions, wall runs, and equipment clearances that shorter pocket tapes cannot cover in a single pull. Its compact case — 14.75 inches long, 8.9 inches wide, and 2.4 inches tall — keeps the tool manageable despite the extended blade length.

Key Features

• 100-foot steel blade with Yellow Ny-Clad coating for corrosion and abrasion resistance
• E4 blade style at 0.5 inches wide for extended reach with controlled flexibility
• SAE (imperial) measurement markings for compatibility with standard US trade practice
• Manual operation with no auto-lock mechanism — simple, durable design
• Compact case at 14.75 x 8.9 x 2.4 inches for a 100-foot tape
• Weighs 2.02 pounds for manageable carry on the job site

Compatibility

Designed as a general-purpose long tape measure for SAE measurement applications across HVAC, plumbing, electrical, and construction trades.

Installation Notes

No installation is required for this tool. Handle the blade with care during full extension to avoid kinking, which can permanently damage the steel. Retract the blade at a controlled speed to prevent snap-back wear on the Ny-Clad coating. Store the tape in a dry location to preserve blade finish and case integrity.

Technical Specifications

• Blade Length: 100 feet
• Blade Width: 0.5 inches
• Blade Material: Steel
• Blade Finish: Yellow Ny-Clad
• Blade Style: E4
• Measurement Type: SAE (Imperial)
• Auto-Lock: No
• Overall Length: 14.75 inches
• Overall Width: 8.9 inches
• Overall Height: 2.4 inches
• Weight: 2.02 pounds
• UPC: 037103194695

Standard Information

• Brand: APEX
• Manufacturer Part Number: PS1806N
