Apex FM050CM Fiberglass Tape Measure 164 Ft Metric

Product Description

The APEX FM050CM is a fiberglass long tape measure designed for metric layout and measurement work in the field. The 164-foot fiberglass blade resists moisture, chemicals, and stretching, making it a dependable choice for outdoor surveying, utility work, and large-scale construction layout. The 0.5-inch-wide blade rides on a C3-style configuration supported by 4 arms for even winding and consistent retraction. The rawhide-colored case measures 15.3 inches long, 9 inches wide, and 1.8 inches tall. At 1.75 pounds, the unit is substantial enough to handle daily field use without being burdensome to carry.

This tape is suited for trade professionals who need metric measurement capability over long distances. Typical applications include surveying, irrigation and drainage layout, electrical conduit runs, large-footprint construction staking, and utility line measurement. The fiberglass blade material makes it appropriate for use near energized equipment where a steel blade would be a conductivity hazard. It is sold as an individual unit.

Key Features

• 164-foot fiberglass blade rated for metric measurement
• C3 blade style with 4-arm winding configuration for even retrieval
• 0.5-inch blade width for legibility at extended distances
• Fiberglass construction resists moisture, chemicals, and electrical conductivity risks
• Rawhide case with compact 15.3 x 9 x 1.8 inch profile
• Lightweight at 1.75 pounds for all-day field carry

Compatibility

Designed as a general-purpose long fiberglass tape measure suitable for metric layout applications in construction, utility, and field surveying work.

Installation Notes

Inspect the blade for kinks, fraying, or damage before each use, as a compromised fiberglass blade can snap under tension. When rewinding, guide the blade evenly across the spool arms to prevent bunching or uneven layering that shortens tape life. Store the tape dry and away from direct UV exposure when not in use to preserve blade markings and case integrity.

Technical Specifications

• Blade Length: 164 ft
• Blade Material: Fiberglass
• Blade Style: C3
• Blade Width: 0.5 inches
• Measurement Type: Metric
• Number of Arms: 4
• Overall Length: 15.3 inches
• Overall Width: 9 inches
• Overall Height: 1.8 inches
• Case Color: Rawhide
• Weight: 1.75 pounds
• UOM: Each

Standard Information

• Brand: APEX
• Manufacturer Part Number: FM050CM
