Apex FE150 Fiberglass Tape Measure 150 Ft

Product Description

The APEX FE150 is a 150-foot fiberglass measuring tape designed for layout and measurement tasks in the field. The fiberglass blade resists moisture, stretching, and corrosion, making it a reliable choice for outdoor use on job sites where steel tapes would be prone to rust or wind interference. The blade measures 0.5 inches wide and is marked in SAE (imperial) graduations. The four-arm frame provides a stable grip during extended pulls. This tape is used by plumbers, electricians, HVAC installers, and general contractors who need a long-range measuring tool for rough layout work.

The FE150 is suited for residential and light commercial construction layout, utility runs, trench measurement, and any application requiring a long tape in wet or humid conditions. The fiberglass construction holds its length better than cloth tapes under tension, making it appropriate for measuring longer runs of conduit, pipe, ductwork, or structural framing where accuracy across distance matters.

Key Features

• 150-foot fiberglass blade resists moisture, corrosion, and stretch
• 0.5-inch blade width in C1 style for easy reading in the field
• SAE (imperial) graduations for standard trade measurement
• Four-arm frame construction for a secure, balanced hold
• Compact housing: 14.9 inches long, 8.9 inches wide, 2.1 inches tall

Compatibility

Designed as a general-purpose long-range fiberglass tape measure suited for trade and construction layout applications requiring SAE measurement.

Installation Notes

No power source or mechanical installation is required. When using a long fiberglass tape, walk the tape out fully before taking measurements to avoid kinks that can affect accuracy. Rewind slowly and evenly to prevent blade bunching inside the housing. Keep the blade clean of debris before rewinding to extend the life of the markings.

Technical Specifications

• Blade Length: 150 feet
• Blade Width: 0.5 inches
• Blade Material: Fiberglass
• Blade Style: C1
• Measurement Type: SAE
• Number of Arms: 4
• Overall Length: 14.9 inches
• Overall Width: 8.9 inches
• Overall Height: 2.1 inches
• Weight: 1.82 pounds

Standard Information

• Brand: APEX
• Manufacturer Part Number: FE150
